Libec’s unique balance stabilizer mechanism prevents even the slightest wobble on the image caused by the
spring-back effect at a stopping tilt movement. In addition, this mechanism greatly simplifies the strict adjustment procedures needed for perfect balancing. First, turn the tilt torque dial to 1 and balance the camera lengthwise. Then, adjust the spring tension by turning the counterbalance adjustment knob. Tilt the camera, once the camera remains stationary, then the counterbalance adjustment is complete. This way, the “perfect counterbalance” is easily achieved, which ensures a stable image even when the pan handle is released from the shooter’s hands.
Generally, the spring tension gets stronger as the counterbalance adjustment knob is turned clockwise, increasing tension on the knob. This difficulty is simplified by the head’s smooth balancing system which stabilizes the turning force efficiently. The knob can be turned with
constant force and offers easy and speedy adjustments.
Система регулировки
плавности перемещения
The sealed torque unit contributes to the smooth start and stop of pan and tilt movement, and produces precise camerawork just as intended. In addition, specific silicon grease is applied to ensure ordinary pan and tilt
movement at a wide temperature range from
-40° C/-40° F up to +60° C/+140° F. The variable
seven-step torque switch system covers remarkably wide torque range, by which an optimum torque is selectable
according to every shooting conditions and circumstances.
