RC-50
Leg lock knob
Related Items
RC-50
Leg lock knob
| System components | |
|---|---|
| Head: LX10 Head | Tripod: RT50B |
| Spreader: BR-6B | Large rubber feet : FP-2B |
| Case: RC-50 | |
| Operation manual | |
|---|---|
| LX10 Head | RT50B |
| BR-6B | FP-2B |
| Specification sheet | |
| LX10 M | LX10 Head |
| RT50B | BR-6B |
| FP-2B | RC-50 |
| Service parts | |
| LX10 Head | RT50B |
| BR-6B | FP-2B |
| Specifications | |
|---|---|
| Payload | Payload 16kg / 35lb |
| Counterbalance | FIX |
| Drag mode | 2STEP |
| Tilt angle | +85° / -65° |
| Temperature range | -20°C to +60°C / -4°F to +140°F |
| Bubble level | Non illuminated |
| Camera plate | Sliding plate |
| Sliding range | +/-50mm / 2" |
| Head base | 100mm ball |
| Plate attachment | 3/8" screw × 2 |
| Spare screw | 3/8" screw |
| Weight | 7.4kg / 16.3lb |
| Height | 83 to 171.5cm / 32.5 to 67.5" |
| Head attachment | 100mm bowl |
| Section | 2-Stage |
| LX10 Counterbalance chart |
|---|
 |
